Ball float steam traps are crucial devices for removing condensate from a steam system, ensuring the supplied steam remains dry and clean to optimize the efficiency of heat exchange equipment. However, a paradox often occurs: the very device designed to save energy can become a significant source of steam loss if it is not properly insulated.

Challenges in Insulating Ball Float Steam Traps

Insulating ball float steam traps involves profound technical issues that directly impact their operational mechanics:

Radiated Heat Loss Leading to Steam Waste: This is the most critical issue. The body of the steam trap is very hot and constantly radiates heat into the environment. This heat loss can cause a portion of the hot steam (live steam) inside the trap body to condense back into water. This causes the steam trap to cycle (discharge) unnecessarily, leading to mechanical wear and the loss of valuable live steam.
Bulky and Unique Shape: Ball float steam traps often have a round or square shape, are quite bulky compared to the pipeline, and include flanges and covers. This shape is very difficult to seal completely with conventional, rigid insulation materials.
Obstruction of Inspection and Maintenance: A steam trap is a mechanical device that requires periodic inspection and maintenance to ensure it operates correctly. A permanent insulation layer makes removing the cover to inspect the internal float mechanism extremely costly and time-consuming.
Burn Hazards for Personnel: The surface of the steam trap reaches a temperature equivalent to that of the steam, posing a major hazard to technicians working nearby.

The Optimal Solution: Custom-Fitted Insulation Jackets for Ball Float Steam Traps

Custom-fitted insulation jackets are designed to completely resolve the steam trap paradox, helping it operate at peak efficiency and with maximum energy savings.

Retaining Heat in the Trap Body to Prevent Steam Loss: By preventing radiated heat loss, the insulation jacket keeps the trap body hot. This prevents live steam from wastefully condensing inside the trap. As a result, the steam trap cycles less frequently, discharging only when there is actual condensate, which saves steam and significantly reduces wear and tear.
Snug-Fit Design for Optimal Efficiency: Each insulation jacket is tailored to the exact 3D shape of a specific steam trap model, ensuring it completely covers the entire surface without gaps to maximize its heat retention capability.
Flexible Removal/Installation for Instant Maintenance: When the internal mechanism needs to be checked, operators can easily remove the insulation jacket in just a minute. After maintenance is complete, the jacket is quickly reinstalled, ready for service with no additional costs.
Extending the Lifespan of the Steam Trap: By reducing unnecessary cycling, the insulation jacket reduces wear on mechanical parts like the float mechanism, valve, and discharge orifice, thereby extending the steam trap’s life cycle.
Absolute Safety for Operators: The insulation jacket lowers the surface temperature of the steam trap to a safe level, completely eliminating the risk of burns, which is especially important in confined spaces.

Insulating a ball float steam trap isn’t just about saving energy lost to the environment; more importantly, it helps the trap itself operate more efficiently, preventing internal steam loss.

Do you hear your steam traps cycling continuously? That could be a sign of heat loss. Contact us, and we can help you with a diagnosis.
